Description

At Lumbatech, we are pleased to introduce the high-quality security solutions from CAME.

CAME Guardian is a reliable and robust full-height turnstile manufactured by the Italian company, CAME S.

Features

Control and Integration Options

The ENTRY and EXIT commands allow users to pass through the turnstile, while the turnstile automatically locks after passage, or after a predetermined time if no one passes.

The LOCK command will lock the turnstile and cancel any ENTRY or EXIT commands.

The EMERGENCY command is used in emergency situations, allowing the turnstile to open and rotate even when the LOCK command is active.

Easy to Integrate

CAME Guardian is also easily integrated with CAME RBM21 and CAME RBM84 systems to achieve a complete transit control system.

LED Lighting

The CAME Guardian turnstile is equipped with LED lights to illuminate the passage area. A standard stop-go traffic light is also installed at the top of the turnstile.

AISI 304 Stainless Steel Version

CAME Guardian is also available in an AISI 304 stainless steel version upon request. This product offers optimal durability in various weather conditions without compromising its aesthetic appeal.

230 V AC Electric Motor

CAME Guardian features a reliable 230 V AC electric motor that ensures smooth and seamless turnstile rotation. The CAME Guardian also includes an automatic release feature during power outages.

Specifications

Protection rating (IP)

PSHPS01: 44

PSGS3 - PSGS4: 44

PSGD3 - PSGD4: 44

Power supply (V-50/60 Hz)

PSHPS01: -

PSGS3 - PSGS4: 120-230 AC

PSGD3 - PSGD4: 120-230 AC

Operating power supply (V)

PSHPS01: 24 DC

PSGS3 - PSGS4: 24 DC

PSGD3 - PSGD4: 24 DC

Draw (mA)

PSHPS01: -

PSGS3 - PSGS4: 223

PSGD3 - PSGD4: 446

Weight (kg)

PSHPS01: 400

PSGS3 - PSGS4: 350

PSGD3 - PSGD4: 650

Operating temperature (°C/°F)

PSHPS01: -20 ÷ +55/-4 ÷ +131

PSGS3 - PSGS4: -20 ÷ +55/-4 ÷ +131

PSGD3 - PSGD4: -20 ÷ +55/-4 ÷ +131



Downloads

Brosur CAME Guardian | Turnstile
