Suprema BioStation 3 Max
Suprema BioStation 3 Max
Share:
Choose how you want to continue
Online purchase needs a unit price on the product record. Without a price, this cannot be added to the cart.
Includes installation request
Online purchase needs a unit price on the product record. Without a price, this cannot be added to the cart.
Description/features translation is in progress. Technical specifications remain unchanged.
Description
BioStation 3 Max is the flagship biometric terminal from Suprema designed for identity-based security and enterprise compliance. Featuring high-performance edge AI, dual-camera liveness detection, and a capacity of up
Features
Identity Intelligence
BioStation 3 Max keeps recognizing you — from formal to casual styles. The Suprema AI engine keeps the check-in process seamless, even when hairstyles, poses, or expressions change.
Specifications
| Item | BS3M-OAPB | BS3M-ODB | BS3M-APB | BS3M-DB |
|---|---|---|---|---|
| Biometrik | Face, Fingerprint | Face, Fingerprint | Face | Face |
| Opsi kartu RF | 125kHz EM, HID Prox & 13.56MHz MIFARE, MIFARE Plus, DESFire, DESFire EV1/EV2/EV3 1) , FeliCa, iCLASS SE/SR/Seos | 125kHz EM & 13.56MHz MIFARE, MIFARE Plus, DESFire, DESFire EV1/EV2/EV3 1) , FeliCa | 125kHz EM, HID Prox & 13.56MHz MIFARE, MIFARE Plus, DESFire, DESFire EV1/EV2/EV3 1) , FeliCa, iCLASS SE/SR/Seos | 125kHz EM & 13.56MHz MIFARE, MIFARE Plus, DESFire, DESFire EV1/EV2/EV3 1) , FeliCa |
| RF read range 2) | EM/MIFARE/DESFire/HID iCLASS: 50 mm, HID Prox/FeliCa: 30 mm | EM/MIFARE/DESFire: 50 mm, FeliCa: 30 mm | EM/MIFARE/DESFire/HID iCLASS: 50 mm, HID Prox/FeliCa: 30 mm | EM/MIFARE/DESFire: 50 mm, FeliCa: 30 mm |
| Kartu seluler | NFC, BLE | NFC, BLE | NFC, BLE | NFC, BLE |
| QR/Barcode 3) | Supported 4) | Supported 4) | Supported 4) | Supported 4) |
| Scrambled Keypad (PIN) | Supported | Supported | Supported | Supported |
| Peringkat IP | IP65 | IP65 | IP65 | IP65 |
| IK rating | IK06 | IK06 | IK06 | IK06 |
| Authentication Distance 5) | 0.3 ~ 1.3 m | 0.3 ~ 1.3 m | 0.3 ~ 1.3 m | 0.3 ~ 1.3 m |
| Authentication Height | 1.4 ~ 1.9 m | 1.4 ~ 1.9 m | 1.4 ~ 1.9 m | 1.4 ~ 1.9 m |
| Matching speed | Within 0.2 seconds | Within 0.2 seconds | Within 0.2 seconds | Within 0.2 seconds |
| Live Face Detection | Supported | Supported | Supported | Supported |
| Dimensi citra sidik jari | 300 x 400 pixels | 300 x 400 pixels | Not supported | Not supported |
| Resolusi sensor | 500 dpi | 500 dpi | Not supported | Not supported |
| Template | SUPREMA / ISO19794-2 / ANSI-378 | SUPREMA / ISO19794-2 / ANSI-378 | Not supported | Not supported |
| Ekstraktor / pencocok | MINEX certified and compliant | MINEX certified and compliant | Not supported | Not supported |
| Sensor Certificates | FBI PIV and FBI Mobile ID FAP20 | FBI PIV and FBI Mobile ID FAP20 | Not supported | Not supported |
| Deteksi sidik jari hidup | Supported (SW-based) | Supported (SW-based) | Not supported | Not supported |
| Kapasitas pengguna maks. | 100,000 6) | 100,000 6) | 100,000 6) | 100,000 6) |
| Kredensial maks. (1:N) | Face: 50,000 Fingerprint: 100,000 Card: 100,000 | Face: 50,000 Fingerprint: 100,000 Card: 100,000 | Face: 50,000 Card: 100,000 | Face: 50,000 Card: 100,000 |
| Kredensial maks. (1:1) | Face: 100,000 Fingerprint: 100,000 Card: 100,000 PIN: 100,000 | Face: 100,000 Fingerprint: 100,000 Card: 100,000 PIN: 100,000 | Face: 100,000 Card: 100,000 PIN: 100,000 | Face: 100,000 Card: 100,000 PIN: 100,000 |
| Log teks maks. | 5,000,000 | 5,000,000 | 5,000,000 | 5,000,000 |
| Max. Image Log | 50,000 | 50,000 | 50,000 | 50,000 |
| CPU | 1.4 GHz Quad Core | 1.4 GHz Quad Core | 1.4 GHz Quad Core | 1.4 GHz Quad Core |
| Memori | 32 GB Flash + 4 GB RAM | 32 GB Flash + 4 GB RAM | 32 GB Flash + 4 GB RAM | 32 GB Flash + 4 GB RAM |
| Chip kripto | Supported | Supported | Supported | Supported |
| Layar | 7" IPS color LCD | 7" IPS color LCD | 7" IPS color LCD | 7" IPS color LCD |
| Resolusi layar | 800 x 1280 pixels | 800 x 1280 pixels | 800 x 1280 pixels | 800 x 1280 pixels |
| Camera | IR: 2M pixels Visual: 2M pixels | IR: 2M pixels Visual: 2M pixels | IR: 2M pixels Visual: 2M pixels | IR: 2M pixels Visual: 2M pixels |
| Suara | 16 bit | 16 bit | 16 bit | 16 bit |
| Suhu operasi | - 20 c 50 c | - 20 c 50 c | - 20 c 50 c | - 20 c 50 c |
| Suhu penyimpanan | - 40 c 70 c | - 40 c 70 c | - 40 c 70 c | - 40 c 70 c |
| Kelembapan operasi | 0 % ~ 80 %, non-condensing | 0 % ~ 80 %, non-condensing | 0 % ~ 80 %, non-condensing | 0 % ~ 80 %, non-condensing |
| Kelembapan penyimpanan | 0 % ~ 90 %, non-condensing | 0 % ~ 90 %, non-condensing | 0 % ~ 90 %, non-condensing | 0 % ~ 90 %, non-condensing |
| Berat | Device: 640 g Bracket: 206 g (including washers and bolts) | Device: 640 g Bracket: 206 g (including washers and bolts) | Device: 565 g Bracket: 187 g (including washers and bolts) | Device: 565 g Bracket: 187 g (including washers and bolts) |
| Dimensi (P×L×T, mm) | Device: 119.8 x 268.3 x 23.5 (Top) / 49.6 (Bottom) (mm) Bracket: 98.4 x 251.4 (mm) | Device: 119.8 x 268.3 x 23.5 (Top) / 49.6 (Bottom) (mm) Bracket: 98.4 x 251.4 (mm) | Device: 119.8 x 233 x 23.5 (mm) Bracket: 98.4 x 223.3 (mm) | Device: 119.8 x 233 x 23.5 (mm) Bracket: 98.4 x 223.3 (mm) |
| Sertifikasi | CE(CE models only), UKCA, KC, FCC, IC, RCM, RoHS, REACH, WEEE, SIG, MIC, TELEC, ETL Listed to UL 294 | CE(CE models only), UKCA, KC, FCC, IC, RCM, RoHS, REACH, WEEE, SIG, MIC, TELEC, ETL Listed to UL 294 | CE(CE models only), UKCA, KC, FCC, IC, RCM, RoHS, REACH, WEEE, SIG, MIC, TELEC, ETL Listed to UL 294 | CE(CE models only), UKCA, KC, FCC, IC, RCM, RoHS, REACH, WEEE, SIG, MIC, TELEC, ETL Listed to UL 294 |
| Ethernet | Supported (10/100/1000 Mbps, auto MDI/MDI-X) | Supported (10/100/1000 Mbps, auto MDI/MDI-X) | Supported (10/100/1000 Mbps, auto MDI/MDI-X) | Supported (10/100/1000 Mbps, auto MDI/MDI-X) |
| Protokol jaringan | TCP, UDP | TCP, UDP | TCP, UDP | TCP, UDP |
| RS-485 | 1 ch Master / Slave (Selectable) | 1 ch Master / Slave (Selectable) | 1 ch Master / Slave (Selectable) | 1 ch Master / Slave (Selectable) |
| Protokol RS-485 | OSDP V2 compliant | OSDP V2 compliant | OSDP V2 compliant | OSDP V2 compliant |
| Wiegand | 1 ch Input, 1 ch Output | 1 ch Input, 1 ch Output | 1 ch Input, 1 ch Output | 1 ch Input, 1 ch Output |
| Input | 3 ch Inputs | 3 ch Inputs | 3 ch Inputs | 3 ch Inputs |
| Relay | 1 relay | 1 relay | 1 relay | 1 relay |
| USB | USB 2.0 (Type C) | USB 2.0 (Type C) | USB 2.0 (Type C) | USB 2.0 (Type C) |
| Port ekspansi USB | Supported | Supported | Supported | Supported |
| PoE+ 7) | Supported (IEEE 802.3at compliant) | Not supported | Supported (IEEE 802.3at compliant) | Not supported |
| Intercom | Supported | Supported | Supported | Supported |
| RTSP (Real Time Streaming Protocol) | Supported | Supported | Supported | Supported |
| Tamper | Supported | Supported | Supported | Supported |
| Daya | 12 Vdc Current: Max. 2.1 A 24 Vdc Current: Max. 1 A | 12 Vdc Current: Max. 2.1 A 24 Vdc Current: Max. 1 A | 12 Vdc Current: Max. 2.1 A 24 Vdc Current: Max. 1 A | 12 Vdc Current: Max. 2.1 A 24 Vdc Current: Max. 1 A |
Downloads
Brosur Suprema BioStation 3 Max
